BC139 TRANSISTOR BJT PNP TO39

Type Designator: BC136

Material of Transistor: Si

Polarity: NPN

Absolute Maximum Ratings
Maximum Collector Power Dissipation (Pc): 0.3 W

Maximum Collector-Base Voltage |Vcb|: 60 V

Maximum Collector-Emitter Voltage |Vce|: 40 V

Maximum Emitter-Base Voltage |Veb|: 5 V

Maximum Collector Current |Ic max|: 0.1 A

Max. Operating Junction Temperature (Tj): 125 °C

Electrical Characteristics
Transition Frequency (ft): 60 MHz

Collector Capacitance (Cc): 25 pF

Forward Current Transfer Ratio (hFE), MIN: 40

Noise Figure, dB: -

Package: TO106
